APC BK500 uninterruptible power supply (UPS) 0.5 kVA 300 W

Manufacturer: APC Product Code: 18786590 EAN: 07313040163042 MPN: BK500

APC BK500, 0.5 kVA, 300 W, 480 J, 45 dB, Sealed Lead Acid (VRLA), 2.4 min
Read more...

Product Information

Information
Manufacturer	APC
Product code	18786590
EAN	07313040163042
Manufacturer part number	BK500
Category	UPS hardware

Features
Output power capacity	0.5 kVA
Output power	300 W
Audible alarm(s)	Y
Cable length	1.83 m
Certification	C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE
Harmonized System (HS) code	85078000
Input connection type	IEC-320-C14
Filtering	Y

Power
Surge energy rating	480 J
Nominal input voltage	230 V

Other features
Noise level	45 dB
USB 2.0 ports quantity	1
Output connections	(3) NEMA 5-15R, (3) NEMA 5-15R
Dimensions (WxDxH)	91 x 284 x 165 mm
Nominal output voltage	120 V
Package dimensions (WxDxH)	241 x 368 x 178 mm

Ports & interfaces
Number of output IEC jumpers	2
Modem (RJ-11) ports	1
Interface	Serial, USB

Rear panel I/O ports
Serial ports quantity	1

Battery
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at full load	2.4 min
Typical backup time at half load	13.9 min
Battery recharge time	6 h

Design
Product colour	Beige
LED indicators	Y

Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m

Weight & dimensions
Weight	6.27 kg
Package weight	6.95 kg

Logistics data
Products per pallet	80 pc(s)

Product Description

APC Back-UPS CS, 300 Watts / 500 VA,Input 120V / Output 120V, Interface Port DB-9 RS-232, USB.

Includes: CD with software, Cord management straps, USB cable, User Manual.
