APC Smart-UPS On-Line Double-conversion (Online) 8 kVA 8000 W 10 AC outlet(s)
APC Smart-UPS On-Line, Double-conversion (Online), 8 kVA, 8000 W, Sine, 100 V, 476 V
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | APC |
| Product code | 07178597 |
| EAN | 05712505310311 |
| Manufacturer part number | AUAPCO3TSRT08T0 |
| Category | UPS hardware |
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 8 kVA |
| Output power | 8000 W |
| Waveform | Sine |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 476 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Output frequency regulation | 50/60 Hz |
| Number of output phases | 1 |
| Crest factor | 3:1 |
| Emergency Power Off (EPO) | Y |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Surge protection | Y |
| Audible alarm(s) | Y |
| Auto-restart | Y |
| Certification | REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
| Harmonized System (HS) code | 85078000 |
| Power | |
|---|---|
| Surge energy rating | 480 J |
| Other features | |
|---|---|
| Noise level | 55 dB |
| Ports & interfaces | |
|---|---|
| AC outlet types | C13 coupler, C19 coupler |
| Power plug | Terminal |
| AC outlets quantity | 10 AC outlet(s) |
| Number of output IEC jumpers | 3 |
| USB port | Y |
| Serial interface | Y |
| Serial interface type | RJ-45 |
| SmartSlot | Y |
| Battery | |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 1728 VAh |
| Battery life (max) | 5 year(s) |
| Battery recharge time | 1.5 h |
| Hot-swap battery | Y |
| Automatic battery test | Y |
| Cold start | Y |
| Design | |
|---|---|
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Status |
| International Protection (IP) code | IP20 |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Sustainability | |
|---|---|
| Sustainability certificates | RoHS, ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Width | 263 mm |
| Depth | 715 mm |
| Height | 432 mm |
| Weight | 111.8 kg |
| Package weight | 126.8 kg |
| Packaging content | Web/SNMP Management Card |
| Packaging data | |
|---|---|
| Package width | 600 mm |
| Package depth | 1000 mm |
| Package height | 461 mm |
| Quick installation guide | Y |
| Software CD | Y |
| Packaging content | |
|---|---|
| Cables included | USB cable |
| Warranty card | Y |
| Security | |
|---|---|
| Temperature sensor | Y |
| Logistics data | |
|---|---|
| Products per pallet | 1 pc(s) |
Product Description
APC Smart-UPS On-Line,8000 Watts /8000 VA,Input 230V /Output 230V, Interface Port Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB, Extended runtime model
Includes: CD with software, Documentation CD, Installation guide, Temperature Probe, USB cable, Warranty card
Includes: CD with software, Documentation CD, Installation guide, Temperature Probe, USB cable, Warranty card
