APC Smart-UPS XL Modular 1500VA 230V 1.5 kVA 1425 W
APC Smart-UPS XL Modular 1500VA 230V, 1.5 kVA, 1425 W, 490 J, 11.9 min, 28.3 min, RBC43
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | APC |
| Product code | 18786219 |
| EAN | 00731304224556 |
| Manufacturer part number | SUM1500RMXLI2U |
| Category | UPS hardware |
| Features | |
|---|---|
| Output power capacity | 1.5 kVA |
| Output power | 1425 W |
| Emergency Power Off (EPO) | Y |
| Audible alarm(s) | Y |
| Cable length | 3 m |
| Certification | C-tick,CE,EN 50091-2,EN 55022 Class A,EN 61000-3-2,GOST |
| Harmonized System (HS) code | 85078000 |
| Input connection type | IEC-320 C14 |
| Power | |
|---|---|
| Surge energy rating | 490 J |
| Battery type | VRLA |
| Nominal input voltage | 230 V |
| Ports & interfaces | |
|---|---|
| Number of output IEC jumpers | 2 |
| Interface | DB-9 RS-232, RJ-45 10/100 Base-T, USB |
| Battery | |
|---|---|
| Typical backup time at full load | 11.9 min |
| Typical backup time at half load | 28.3 min |
| Replacement battery cartridge | RBC43 |
| Design | |
|---|---|
| Product colour | Black |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Weight & dimensions | |
|---|---|
| Weight | 47 kg |
| Other features | |
|---|---|
| Output connections | (9) IEC 320 C13 |
| Dimensions (WxDxH) | 600 x 980 x 250 mm |
| Nominal output voltage | 230 V |
| Output voltage note | 220: 230 / 240 |
| Networking features | Y |
| I/O ports | AP9619 |
Product Description
APC Smart-UPS XL, 1500VA/1425W, Input 230V/Output 230V, Interface Port DB-9 RS-232, RJ-45 10/100 Base-T, USB, Extended runtime model, Rack Height 2 U
Includes: CD with software, Installation Guide, Rack Mounting Brackets, Rack Mounting support rails, Smart UPS signalling RS-232 cable, USB cable, User Manual, Web/SNMP Management Card
Includes: CD with software, Installation Guide, Rack Mounting Brackets, Rack Mounting support rails, Smart UPS signalling RS-232 cable, USB cable, User Manual, Web/SNMP Management Card
Features: Adjustable voltage-transfer points, Automatic internal bypass,
Automatic self-test, Boost and Trim Automatic Voltage Regulation (AVR),
Cold-start capable, Disconnected battery notification, Global safety approvals, Hot-swappable batteries, LED status indicators, Modular design,
Network manageable, Rack/Tower Convertible, Safety-agency approved,
Scalable runtime, Serial Connectivity, SmartSlot, Temperature-compensated battery charging, USB Connectivity, User-replaceable batteries,
User-replaceable power modules.
