DELL MR2416 61 cm (24") 1920 x 1200 pixels WUXGA LED White
DELL MR2416, 61 cm (24"), 1920 x 1200 pixels, WUXGA, LCD, 15 ms, White
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | DELL |
| Product code | 228653432 |
| EAN | 05397063745111 |
| Manufacturer part number | MRJ9P |
| Category | Monitors |
| Display | |
|---|---|
| Display diagonal | 61 cm (24") |
| Display resolution | 1920 x 1200 pixels |
| Native aspect ratio | 16:10 |
| Display technology | LED |
| Touchscreen | N |
| HD type | WUXGA |
| Panel type | IPS |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Display number of colours | 16.78 million colours |
| Display brightness (typical) | 300 cd/m² |
| Response time | 15 ms |
| Display surface | Matt |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.27 x 0.27 mm |
| Horizontal scan range | 30 - 83 kHz |
| Vertical scan range | 50 - 76 Hz |
| Viewable size, horizontal | 51.8 cm |
| Viewable size, vertical | 32.4 cm |
| Colour gamut | 99% |
| sRGB coverage (typical) | 110% |
| On Screen Display (OSD) | Y |
| Design | |
|---|---|
| Backlight type | Edge LED |
| Market positioning | Medical |
| Product colour | White |
| Feet colour | Silver |
| Cable lock slot type | Kensington |
| Tilt adjustment | Y |
| Features | |
|---|---|
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 mm |
| Other features | |
|---|---|
| 3D | N |
| Compliance industry standards | FDA Class I, ANSI/AAMI ES 60601-1, FCC Part 15 Class B, ICES-003 Level B, IEC/EN 60601-1, IEC/EN 60601-1-2 |
| Quick start guide | Y |
| Display | LCD |
| Dell E-Value Code | MR2416 |
| Performance | |
|---|---|
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
| Cable lock slot | Y |
| TV tuner integrated | N |
| Audio | |
|---|---|
| Built-in speaker(s) | N |
| Camera | |
|---|---|
| Built-in camera | N |
| Ports & interfaces | |
|---|---|
| Built-in USB hub | Y |
| USB hub version | 2.0 |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | N |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Ergonomics | |
|---|---|
| Swivelling | Y |
| Tilt angle range | -5 - 21° |
| Power | |
|---|---|
| Power consumption (typical) | 29 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 47 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 100 - 250 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.5 A |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 12192 m |
| Packaging content | |
|---|---|
| Stand included | Y |
| Cables included | AC, DisplayPort, HDMI, USB, VGA |
| AC adapter included | Y |
| Weight & dimensions | |
|---|---|
| Width (with stand) | 567 mm |
| Depth (with stand) | 200.3 mm |
| Height (with stand) | 551.6 mm |
| Weight (with stand) | 8.74 kg |
| Width (without stand) | 56.7 cm |
| Depth (without stand) | 5.65 cm |
| Height (without stand) | 37.3 cm |
| Weight (without stand) | 5.2 kg |
| Package weight | 11.9 kg |
| Packaging data | |
|---|---|
| User Guide on CD-ROM | Y |
| Thin Client | |
|---|---|
| Thin client installed | N |
Product Description
Superior grayscale viewing with DICOM-ready images
Dependable image quality: Count on accurate DICOM-ready1 images for precise clinical review.
Maintains brightness: Expect consistent brightness with backlight stabilization control.
Precise color: Each hue is constant across an ultrawide 178°/178° viewing angle.
Easily compatible: Display EMR/EHR applications on the 24-inch screen with 1920 x 1200 resolution and a 16:10 aspect ratio.
Fully cleanable design for effective infection control
Stain detection: Identify blood stains and contaminants easily thanks to a light-colored exterior design.
Convenient protection: Clean-up is simple with this monitor’s smooth exterior, protective covered glass and a fully sealed design that is IP-32 rated.
Simple disinfection: Cleaning liquids with up to 75% concentrated ethyl alcohol solution can be used to disinfect both the monitor’s surface and glass panel.
Observe healthcare standards and improve efficiency
Safe and compliant: Meets medical design standards and safety requirements for medical electrical equipment with IEC 60601-1 compliance.
Secure and out of the way: Keep cables secured and fastened to the monitor with an active screw-on cable clip.
Full adjustability: Switch between portrait and landscape orientation to view images and records. Adjust height, tilt, pivot or swivel the monitor up to 60° left and right for easy screen sharing with patients.
Unmatched reliability
Limited Hardware Warranty
Because it is backed by a 3-Year Limited Hardware Warranty and Advanced Exchange Service, you can purchase your monitor with confidence.
ISO13485 certified
The Dell Medical Review 24 Monitor | MR2416 meets regulatory requirements for the design, development and support of medical displays.
World’s No. 1 Monitor brand
Choose Dell, the top monitor brand for two consecutive years and No. 1 in North America for 15 consecutive years.
