For illustrative purpose only
Doepke 09980408 auxiliary contact
Doepke 09980408, Grey, 230V, 50Hz/60Hz, 20VA ... 25VA
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Doepke |
| Product code | 162149887 |
| EAN | 04014712067103 |
| Manufacturer part number | 09980408 |
Product Description
Installation contactors are electromagnetically operated switches. If a control current flows through the magnetic coil, the main circuit closes the magnetic energiser. As long as the control current flows, the switch-on position is maintained. If the control current is interrupted, a spring forces the disconnection o return of the contacts to their original position. This design means that contactors ensure a galvanic separation between the control circuit and the switched circuit whilst simultaneously allowing high currents to be switched. Installation contactors are only designed in a limited way for release and must be protected against overload and short-circuits by upstream protective devices. Installation contactors in series HS for installation in distribution boards are extremely quiet and have very low-noise switching processes, are highly versatile thanks to their utilization categories and have a long mechanical and electrical service life. The magnetic coil of this series is suitable for continuous operation (100% duty cycle). Devices in this design are operated with a control voltage of 230 V AC.
