EIZO ColorEdge CS2731 LED display 68.6 cm (27") 2560 x 1440 pixels Quad HD Black
EIZO ColorEdge CS2731, 68.6 cm (27"), 2560 x 1440 pixels, Quad HD, LED, 16 ms, Black
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | EIZO |
| Product code | 17771485 |
| EAN | 04995047054580 |
| Manufacturer part number | CS2731-BK |
| Category | Monitors |
| Display | |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 2560 x 1440 pixels |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| HD type | Quad HD |
| Display technology | LED |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Display number of colours | 1.073 billion colours |
| Display brightness (typical) | 350 cd/m² |
| Response time | 16 ms |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.233 x 0.233 mm |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| Digital horizontal frequency | 15 - 89 kHz |
| Digital vertical frequency | 23 - 61 Hz |
| Separate H/V sync | Y |
| DDC/CI | Y |
| RGB colour space | sRGB |
| sRGB coverage (typical) | 100% |
| On Screen Display (OSD) | Y |
| Features | |
|---|---|
| Supported graphics resolutions | 2560 x 1440 |
| Certification | CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE |
| HDCP | Y |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 mm |
| Height adjustment | 15.5 cm |
| USB Power Delivery | Y |
| Performance | |
|---|---|
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
| Flicker-free technology | Y |
| Low Blue Light technology | Y |
| Cable lock slot | Y |
| Swivel angle range | 0 - 344° |
| TV tuner integrated | N |
| Camera | |
|---|---|
| Built-in camera | N |
| Design | |
|---|---|
| Market positioning | Graphics design |
| Product colour | Black |
| Cable lock slot type | Kensington |
| On/off switch | Y |
| Ports & interfaces | |
|---|---|
| Built-in USB hub | Y |
| HDMI | Y |
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports | 2 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Y |
| USB Power Delivery up to | 60 W |
| DVI port | Y |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Rear panel I/O ports | |
|---|---|
| DVI-D ports quantity | 1 |
| Ergonomics | |
|---|---|
| Height adjustment | Y |
| Pivot | Y |
| Pivot angle | -90 - 90° |
| Swivelling | Y |
| Tiltable | Y |
| Tilt angle range | -5 - 35° |
| Power | |
|---|---|
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 36 kWh |
| Power consumption (typical) | 35.7 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 159 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Sustainability | |
|---|---|
| Sustainability certificates | RoHS, ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Width (with stand) | 638 mm |
| Depth (with stand) | 265 mm |
| Height (with stand) | 404.1 mm |
| Weight (with stand) | 10.1 kg |
| Weight (without stand) | 6.5 kg |
| Packaging content | |
|---|---|
| Cables included | AC, HDMI, USB Type-C |
| Other features | |
|---|---|
| Quick start guide | Y |
Product Description
The CS2731 unites precision, colour fidelity and cutting-edge connectivity thanks to its USB-C port. This makes the monitor the central interface for the graphic workflow of sophisticated creatives with high standards. The wide gamut, 16-bit look-up-table and precise factory calibration of the CS2731 allows you to enjoy an unadulterated look at your image files in creative workflows requiring high colour accuracy. Convenient functionalities such as monitor signal transmission, rapid data transfer and the power supply feature for connected devices are enabled with just one USB-C port.
