Intel Celeron G5900 processor 3.4 GHz 2 MB Smart Cache Box

Manufacturer: Intel Product Code: 103449879 EAN: 00735858445863 MPN: BX80701G5900

Intel Celeron G5900, Intel® Celeron® G, LGA 1200 (Socket H5), 14 nm, Intel, G5900, 3.4 GHz
Read more...

Product Information

Processor
Processor family	Intel® Celeron® G
Processor cores	2
Processor socket	LGA 1200 (Socket H5)
Processor lithography	14 nm
Box	Y
Cooler included	Y
Processor manufacturer	Intel
Processor model	G5900
Processor base frequency	3.4 GHz
Processor operating modes	64-bit
Processor threads	2
System bus rate	8 GT/s
Processor cache	2 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	58 W
Memory bandwidth supported by processor (max)	41.6 GB/s
Processor codename	Comet Lake
Maximum internal memory supported by processor	128 GB
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Tjunction	100 °C

Design
Component for	PC
Product type	Processor

Processor special features
Processor ARK ID	199268
Execute Disable Bit	Y
Idle States	Y
Thermal Monitoring Technologies	Y
Supported instruction sets	SSE4.1, SSE4.2
CPU configuration (max)	1
Embedded options available	N
Thermal solution specification	PCG 2015C
Intel® Hyper Threading Technology (Intel® HT Technology)	N
Intel® Identity Protection Technology (Intel® IPT)	Y
Intel® Turbo Boost Technology	N
Intel® Quick Sync Video Technology	Y
Intel® InTru™ 3D Technology	Y
Intel® Clear Video HD Technology (Intel® CVT HD)	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Enhanced Intel SpeedStep Technology	Y
Intel Trusted Execution Technology	N
Intel® Thermal Velocity Boost	N
Intel® Transactional Synchronization Extensions	N
Intel VT-x with Extended Page Tables (EPT)	Y
Intel® Secure Key	Y
Intel Stable Image Platform Program (SIPP)	N
Intel® OS Guard	Y
Intel Clear Video Technology	Y
Intel Software Guard Extensions (Intel SGX)	Y
Intel 64	Y
Intel Virtualization Technology (VT-x)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel Turbo Boost Max Technology 3.0	N
Intel® Optane™ Memory Ready	Y
Intel® Boot Guard	Y
Intel® vPro™ Platform Eligibility	N
Processor package size	37.5 x 37.5 mm

Memory
Memory channels	Dual-channel
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB

Graphics
On-board graphics adapter	Y
Discrete graphics adapter	N
On-board graphics adapter model	Intel® UHD Graphics 610
Discrete graphics adapter model	Not available
Maximum on-board graphics adapter memory	64 GB
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
On-board graphics adapter 4K support	Y
On-board graphics adapter DirectX version	12.0
On-board graphics adapter OpenGL version	4.5
On-board graphics adapter maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics adapter maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics adapter refresh rate at maximum resolution (HDMI)	30 Hz
On-board graphics adapter ID	0x9BA8
Maximum graphics adapter memory	64 GB

Performance
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159

Packaging data
Package type	Retail box

Other information
Maximum resolution & refresh rate (DisplayPort)	4096x2304@60Hz
Bus speed	8 GT/s
Processor ID	0x9BA8

Intel Celeron G5900 Processor (2MB Cache, 3.4 GHz)
