Intel Core i5-7500 processor 3.4 GHz 6 MB Smart Cache
Intel Core i5-7500, Intel® Core™ i5, LGA 1151 (Socket H4), 14 nm, Intel, i5-7500, 3.4 GHz
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Intel |
| Product code | 10249806 |
| EAN | 07330381928383 |
| Manufacturer part number | CM8067702868012 |
| Category | Processors |
| Processor | |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor cores | 4 |
| Processor socket | LGA 1151 (Socket H4) |
| Processor lithography | 14 nm |
| Box | N |
| Cooler included | N |
| Processor manufacturer | Intel |
| Processor model | i5-7500 |
| Processor base frequency | 3.4 GHz |
| Processor operating modes | 64-bit |
| Processor generation | 7th gen Intel® Core™ i5 |
| Processor series | Intel Core i5-7500 Desktop Series |
| Processor threads | 4 |
| System bus rate | 8 GT/s |
| Processor boost frequency | 3.8 GHz |
| Processor cache | 6 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 65 W |
| Stepping | B0 |
| Bus type | DMI3 |
| Processor codename | Kaby Lake |
| Processor code | SSR335 |
| Maximum internal memory supported by processor | 64 GB |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Tjunction | 100 °C |
| Processor cache | 6144 KB |
| Generation | 7th Generation |
| Design | |
|---|---|
| Component for | PC |
| Product type | Processor |
| Features | |
|---|---|
| Compatible chipsets | Intel® B150, Intel® H110, Intel® H170, Intel Q150, Intel® Q170, Intel® Z170 |
| Market segment | Desktop |
| Scalability | 1S |
| PCI Express CEM revision | 3.0 |
| Harmonized System (HS) code | 85423119 |
| Processor special features | |
|---|---|
| Processor ARK ID | 97123 |
| Memory voltage supported by processor | 1.35 V |
| Execute Disable Bit | Y |
| Idle States | Y |
| Thermal Monitoring Technologies | Y |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | Y |
| Thermal solution specification | PCG 2015C |
| Intel® Hyper Threading Technology (Intel® HT Technology) | N |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Y |
| Intel® InTru™ 3D Technology | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Trusted Execution Technology | Y |
| Intel® Memory Protection Extensions (Intel® MPX) | Y |
| Intel® Turbo Boost Technology 2.0 frequency | 3.8 GHz |
| Intel® Transactional Synchronization Extensions | Y |
| Intel Enhanced Halt State | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® Secure Key | Y |
| Intel TSX-NI | Y |
| Intel Stable Image Platform Program (SIPP) | Y |
| Intel® OS Guard | Y |
| Intel Clear Video Technology | Y |
| Intel Software Guard Extensions (Intel SGX) | Y |
| Intel 64 | Y |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Y |
| Intel® Optane™ Memory Ready | Y |
| Intel® Boot Guard | Y |
| Intel® vPro™ Platform Eligibility | Y |
| Processor package size | 37.5 x 37.5 mm |
| Memory | |
|---|---|
| Memory channels | Dual-channel |
| Memory types supported by processor | DDR4-SDRAM, DDR3L-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| ECC | N |
| Supported memory types | DDR4-SDRAM, DDR3L-SDRAM |
| Maximum internal memory | 64 GB |
| Graphics | |
|---|---|
| On-board graphics adapter | Y |
| On-board graphics adapter model | Intel® HD Graphics 630 |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter 4K support | Y |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.5 |
| On-board graphics adapter maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics adapter maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics adapter refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics adapter refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics adapter ID | 5912 |
| Maximum graphics adapter memory | 64 GB |
| Performance | |
|---|---|
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Maximum internal memory | 65536 MB |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Other features | |
|---|---|
| Video decoding | Y |
| Launch date | Q1'17 |
| Status | Launched |
| Maximum memory | 64 GB |
| Last change | 63903513 |
| Product family | 7th Generation Intel Core i5 Processors |
| Other information | |
|---|---|
| Bus bandwidth | 8 |
| Bus type units | GT/s |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| Processor brand name | 7th Gen Intel Core i5 processors |
| Bus speed | 8 GT/s |
| Processor ID | 0x5912 |
Product Description
Turbo Boosted Performance. For Seamless Experiences
Spend more time doing and less time waiting with the unprecedented power and responsiveness of Intel® Turbo Boost Technology 2.0. Longer-lasting battery life and faster re-charging give you the freedom to experience enhanced speed and performance untethered. Create, edit and share 4K content with ease, and discover immersive, full-screen 4K and 360 viewing. In other words, Intel’s best processor just got even better.
The Speed You Need
Equipped with rapid responsiveness, the 7th generation Intel® Core™ processor has the power and speed to keep up with your demands. Open files and programs quickly, plus seamlessly switch between applications and web pages without delay.
Immersive Entertainment
Experience ultra high-definition content with the clarity and sharpness of 4K resolution. Featuring 4x more pixels than full HD screens, you’ll get crisper, clearer images for an immersive viewing like never before.
Hassle Free
Today’s PCs are more hassle-free than ever – log in quickly and easily with facial recognition technology, get 0.5 second wake, and never feel weighed down with new razor-thin devices.
Spend more time doing and less time waiting with the unprecedented power and responsiveness of Intel® Turbo Boost Technology 2.0. Longer-lasting battery life and faster re-charging give you the freedom to experience enhanced speed and performance untethered. Create, edit and share 4K content with ease, and discover immersive, full-screen 4K and 360 viewing. In other words, Intel’s best processor just got even better.
The Speed You Need
Equipped with rapid responsiveness, the 7th generation Intel® Core™ processor has the power and speed to keep up with your demands. Open files and programs quickly, plus seamlessly switch between applications and web pages without delay.
Immersive Entertainment
Experience ultra high-definition content with the clarity and sharpness of 4K resolution. Featuring 4x more pixels than full HD screens, you’ll get crisper, clearer images for an immersive viewing like never before.
Hassle Free
Today’s PCs are more hassle-free than ever – log in quickly and easily with facial recognition technology, get 0.5 second wake, and never feel weighed down with new razor-thin devices.
