Intellinet Gigabit Ethernet to SFP Media Converter, 10/100/1000Base-Tx to SFP slot, empty (Euro 2-pin plug)
Intellinet Gigabit Ethernet to SFP Media Converter, 10/100/1000Base-Tx to SFP slot, empty (Euro 2-pin plug), 1000 Mbit/s, 10Base-T, 100Base-TX, 1000Base-TX, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z, Fast Ethernet, Gigabit Ethernet, 10,100,1000 Mbit/s, 1000 Mbit/s
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Intellinet |
| Product code | 03199824 |
| EAN | 00766623510493 |
| Manufacturer part number | NUITLMC10510493 |
| Category | Networking accessories |
| Features | |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Data transfer rate | 1000 Mbit/s |
| Certification | FCC Class A, CE |
| Input voltage | 12 V |
| Harmonized System (HS) code | 85176990 |
| Network | |
|---|---|
| Converter input interface | 10Base-T, 100Base-TX, 1000Base-TX |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto MDI/MDI-X | Y |
| Cable types supported | Cat5e, Fiber |
| Other features | |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z |
| External power adapter | Y |
| User guide | Y |
| Performance | |
|---|---|
| Duplex system | Full |
| Maximum transfer distance | 100 m |
| Internal | N |
| Optical fiber | |
|---|---|
| Fiber optic connector | SFP |
| Keyboard | |
|---|---|
| Connectivity technology | Wired |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Design | |
|---|---|
| LED indicators | Link, Power |
| Product colour | Black |
| Housing material | Metal |
| Power | |
|---|---|
| Input current | 1.2 A |
| Power consumption (max) | 5 W |
| Weight & dimensions | |
|---|---|
| Width | 70 mm |
| Depth | 96 mm |
| Height | 26 mm |
| Weight | 170 g |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 80% |
Product Description
The Intellinet Network Solutions Gigabit Ethernet to SFP Media Converter is completely transparent to the network so the network performs exactly the way it did before - only now it can support both copper and fibre mediums.
Expands the Size of an Existing Network
Provides fibre connectivity to Ethernet segments, allowing for even further networking expansion between extended workgroups. Also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers.
Enhances the Distance between Networking Devices
Connecting the converter to fibre segments can further extend distances between networking nodes. This can be achieved by direct connection between the converter and a fibre-based node or networking device.
Cabling Flexibility
Network managers can install fibre cabling anywhere within a network without changing the arrangement of copper-based Ethernet. The compact size of the converter allows it to be easily deployed in any narrow desktop location or to be used in a wall-mount installation. Several converters can be simultaneously installed into a 19"; rack-mountable chassis.
Expands the Size of an Existing Network
Provides fibre connectivity to Ethernet segments, allowing for even further networking expansion between extended workgroups. Also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers.
Enhances the Distance between Networking Devices
Connecting the converter to fibre segments can further extend distances between networking nodes. This can be achieved by direct connection between the converter and a fibre-based node or networking device.
Cabling Flexibility
Network managers can install fibre cabling anywhere within a network without changing the arrangement of copper-based Ethernet. The compact size of the converter allows it to be easily deployed in any narrow desktop location or to be used in a wall-mount installation. Several converters can be simultaneously installed into a 19"; rack-mountable chassis.
