Legrand Keor UPS PDU 800VA GR/IT INPUT 8 IEC OUTPUT Standby (Offline) 0.8 kVA 480 W 16 AC outlet(s)
Legrand Keor UPS PDU 800VA GR/IT INPUT 8 IEC OUTPUT, Standby (Offline), 0.8 kVA, 480 W, Sine, 160 V, 290 V
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Legrand |
| Product code | 367608170 |
| EAN | 03414971529397 |
| Manufacturer part number | 310331 |
| Category | UPS hardware |
| Features | |
|---|---|
| UPS topology | Standby (Offline) |
| Output power capacity | 0.8 kVA |
| Output power | 480 W |
| Waveform | Sine |
| Input operation voltage (min) | 160 V |
| Input operation voltage (max) | 290 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 207 V |
| Output operation voltage (max) | 253 V |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 1 Hz |
| Output voltage regulation | 10% |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Output power factor | 0.6 |
| Power protection features | Overdischarge, Overload, Short circuit |
| Auto shut-off | N |
| Certification | EN 62040-1, EN 62040-2 |
| Harmonized System (HS) code | 85078000 |
| Power | |
|---|---|
| Maximum current | 10 A |
| Efficiency | 98% |
| Potential-free output | N |
| Other features | |
|---|---|
| Noise level | 40 dB |
| Performance | |
|---|---|
| Power source type | AC |
| Ports & interfaces | |
|---|---|
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 16 AC outlet(s) |
| Number of type F outputs | 8 |
| USB port | Y |
| USB port type | USB Type-B |
| Battery | |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 9 Ah |
| Number of batteries supported | 1 |
| Typical backup time at half load | 10 min |
| Design | |
|---|---|
| Form factor | Rackmount |
| Product colour | Black, White |
| Rack capacity | 2U |
| LED indicators | Y |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Sustainability | |
|---|---|
| Sustainability compliance | Y |
| Sustainability certificates | CE |
| Logistics data | |
|---|---|
| Pallet net height | 105 cm |
| Pallet net depth | 100 cm |
| Pallet net width | 120 cm |
| Pallet net weight | 303.6 kg |
| Products per pallet | 48 pc(s) |
| Master (outer) case width | 159 mm |
| Master (outer) case length | 528 mm |
| Master (outer) case height | 255 mm |
| Master (outer) case gross weight | 6.33 kg |
| Products per master (outer) case | 1 pc(s) |
| Weight & dimensions | |
|---|---|
| Width | 88 mm |
| Depth | 150 mm |
| Height | 440 mm |
| Weight | 5.5 kg |
| Package weight | 6.01 kg |
| Packaging data | |
|---|---|
| Package width | 88 mm |
| Package depth | 5.81 mm |
| Package height | 440 mm |
Product Description
Keor PDU is a new UPS specifically designed for installation in 19-inch panels and racks.
Its PDU style design with ultra compact dimensions provides 8 sockets with up to 15 minute autonomy in just 2 rack units.
Its PDU style design with ultra compact dimensions provides 8 sockets with up to 15 minute autonomy in just 2 rack units.
