Lenovo 90Y3482 network card Internal Ethernet 40000 Mbit/s
Lenovo 90Y3482, Internal, Wired, PCI Express, Ethernet, 40000 Mbit/s, Black, Green
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Lenovo |
| Product code | 228649929 |
| EAN | 00883436240215 |
| Manufacturer part number | 90Y3482 |
| Category | Võrgukaardid |
| Keyboard | |
|---|---|
| Connectivity technology | Wired |
| Ports & interfaces | |
|---|---|
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 2 |
| PCI version | 3.0 |
| Features | |
|---|---|
| Maximum data transfer rate | 40000 Mbit/s |
| Full duplex | Y |
| Certification | IEC/EN 60950-1:2006 ETSI EN 300 019-2-2 IEC 60068-2- 64, 29, 32 |
| Flow control support | Y |
| Other features | |
|---|---|
| Networking standards | IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3x |
| Receive Side Scaling (RSS) | Y |
| Network | |
|---|---|
| Ethernet interface type | 40 Gigabit Ethernet |
| Ethernet LAN data rates | 40000 Mbit/s |
| Wake-on-LAN ready | Y |
| VLAN tagging | Y |
| iSCSI support | Y |
| Data transmission | |
|---|---|
| Jumbo frames support | Y |
| Performance | |
|---|---|
| Internal | Y |
| Design | |
|---|---|
| Product colour | Black, Green |
| Weight & dimensions | |
|---|---|
| Width | 100 mm |
| Depth | 80 mm |
| Weight | 13 g |
Product Description
The Flex System EN6132 2-port 40Gb Ethernet Adapter and Mellanox ConnectX-3 Mezz 40Gb 2-Port Ethernet Adapter in conjunction with the EN6131 40Gb Ethernet Switch offer the performance that you need to support clustered databases, parallel processing, transactional services, and high-performance embedded I/O applications, which reduces task completion time and lowers the cost per operation.
The EN6132 and ConnectX-3 adapters can help you achieve efficient computing by offloading protocol processing from the CPU and data movement impact, such as RDMA over Converged Ethernet and Send/Receive semantics, which allows more processor power for the application.
The EN6132 and ConnectX-3 adapters can help you achieve efficient computing by offloading protocol processing from the CPU and data movement impact, such as RDMA over Converged Ethernet and Send/Receive semantics, which allows more processor power for the application.
