For illustrative purpose only
LevelOne 48V DC Industrial Power Supply, 240W, DIN-Rail, PoE Ready
LevelOne 48V DC Industrial Power Supply, 240W, DIN-Rail, PoE Ready, 240 W, 90 - 264 V, Over voltage, Overload, Short circuit, 230200 h, IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3,..., China
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | LevelOne |
| Product code | 16545881 |
| EAN | 04015867206508 |
| Manufacturer part number | POW-4851 |
| Category | Toiteplokid |
| Power | |
|---|---|
| Total power | 240 W |
| AC input voltage | 90 - 264 V |
| Maximum current | 5 A |
| Features | |
|---|---|
| Power protection features | Over voltage, Overload, Short circuit |
| Harmonized System (HS) code | 84733020 |
| Performance | |
|---|---|
| Mean time between failures (MTBF) | 230200 h |
| Safety | IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024 |
| Logistics data | |
|---|---|
| Country of origin | China |
| Design | |
|---|---|
| Product colour | Blue, Silver |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 125.2 mm |
| Depth | 113.5 mm |
| Height | 63 mm |
| Weight | 1 kg |
| Package weight | 1 kg |
| Packaging data | |
|---|---|
| Package width | 125.2 mm |
| Package depth | 113.5 mm |
| Package height | 63 mm |
| Other features | |
|---|---|
| Technical features | 48V DC Out |
Product Description
The POW-4851 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.
