LevelOne Print Server, 2 x USB, 1 x Parallel
LevelOne Print Server, 2 x USB, 1 x Parallel, Grey, Activity, Link, Power, Status, Taiwan, Ethernet LAN, IEEE 802.3, IEEE 802.3u, 10,100 Mbit/s
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | LevelOne |
| Product code | 16487579 |
| EAN | 05704174003342 |
| Manufacturer part number | 501033 |
| Category | Servers |
| Performance | |
|---|---|
| Internal | N |
| Design | |
|---|---|
| Product colour | Grey |
| LED indicators | Activity, Link, Power, Status |
| Features | |
|---|---|
| IPP support | Y |
| USB connector type | USB Type-A |
| Linux operating systems supported | Y |
| Certification | CE, FCC Class B |
| Network | |
|---|---|
| DHCP client | Y |
| Network connection type | Ethernet LAN |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Logistics data | |
|---|---|
| Country of origin | Taiwan |
| Other features | |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3u |
| USB 2.0 ports quantity | 2 |
| Other operating systems supported | Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x |
| Protocols | |
|---|---|
| Supported network protocols | TCP/IP, IPX, NetBEUI, AppleTalk, LPR, SMB over TCP/IP, RAW |
| Management features | |
|---|---|
| Web-based management | Y |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Parallel ports quantity | 1 |
| DC-in jack | Y |
| Software | |
|---|---|
| Mac operating systems supported | Mac OS 8.1, Mac OS 8.5, Mac OS 8.6, Mac OS 9.0, Mac OS 9.1, Mac OS 9.2 |
| Weight & dimensions | |
|---|---|
| Width | 100 mm |
| Depth | 180 mm |
| Height | 35 mm |
| Weight | 255 g |
| Package weight | 970 g |
| Packaging data | |
|---|---|
| Package width | 370 mm |
| Package depth | 382 mm |
| Package height | 41.3 mm |
| Packaging content | |
|---|---|
| Manual | Y |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 50% |
| Storage temperature (T-T) | -5 - 65 °C |
| Storage relative humidity (H-H) | 0 - 70% |
| Operating altitude | 0 - 80 m |
Product Description
Product Overview
The LevelOne FPS-1033 print server is an ideal network printing solution for small offices, home offices, schools and other businesses that require printer sharing over the same network. The FPS-1033 is a multi-port Fast Ethernet Print Server and provides network printer sharing for both USB and Parallel printers.
Multi Printer Support
The FPS-1033 Multi Port print server provides simultaneous connectivity to two USB and one Parallel printers. It supports the USB 2.0 standard for high-speed printing.
Multi OS and Network Printing Protocol Support
The FPS-1033 Multi Port Print Server supports Windows ME, 2000,2003 and XP operating systems as well as Mac OS 8.1 and higher and UNIX/Linux and Netware (Bindery/NDS). Network Print Protocol supported includes TCP/IP, IPX, NetBEUI, AppleTalk, LPR, SMB over TCP/IP and IPP for flexible use with different network clients connected to the same office network.
Easy Installation Wizard
The LevelOne FPS-1033 is easily configurable using a Web Browser or Windows based configuration program included with the CD-ROM. The print server is easily managed through a Web based user interface and the firmware is upgradeable through TFTP, the windows set-up program or the Web based user interface.
- Multi-Port print server for network print sharing
- USB 2.0 interface
- Simple setup with user-friendly interface
- Support multiple network printing protocols
- Support multiple operating systems
The LevelOne FPS-1033 print server is an ideal network printing solution for small offices, home offices, schools and other businesses that require printer sharing over the same network. The FPS-1033 is a multi-port Fast Ethernet Print Server and provides network printer sharing for both USB and Parallel printers.
Multi Printer Support
The FPS-1033 Multi Port print server provides simultaneous connectivity to two USB and one Parallel printers. It supports the USB 2.0 standard for high-speed printing.
Multi OS and Network Printing Protocol Support
The FPS-1033 Multi Port Print Server supports Windows ME, 2000,2003 and XP operating systems as well as Mac OS 8.1 and higher and UNIX/Linux and Netware (Bindery/NDS). Network Print Protocol supported includes TCP/IP, IPX, NetBEUI, AppleTalk, LPR, SMB over TCP/IP and IPP for flexible use with different network clients connected to the same office network.
Easy Installation Wizard
The LevelOne FPS-1033 is easily configurable using a Web Browser or Windows based configuration program included with the CD-ROM. The print server is easily managed through a Web based user interface and the firmware is upgradeable through TFTP, the windows set-up program or the Web based user interface.
- Multi-Port print server for network print sharing
- USB 2.0 interface
- Simple setup with user-friendly interface
- Support multiple network printing protocols
- Support multiple operating systems
