Manhattan Linear CCD Handheld Barcode Scanner, USB, 500mm Scan Depth, IP54 rating, Cable length 1.5m, Max Ambient Light 100,000 lux (sunlight), Black, Three Year Warranty, Box
Manhattan Linear CCD Handheld Barcode Scanner, USB, 500mm Scan Depth, IP54 rating, Cable length 1.5m, Max Ambient Light 100,000 lux (sunlight), Black, Three Year Warranty, Box, Handheld bar code reader, 1D, CCD, Code 11, Code 128, Code 32, Code 39, Code 93, GS1-128 (UCC/EAN-128), JAN, 50 cm, 500 reads/s
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Manhattan |
| Product code | 03202797 |
| EAN | 05054337301564 |
| Manufacturer part number | 178433 |
| Category | Barcodescanner |
| Features | |
|---|---|
| Type | Handheld bar code reader |
| Certification | FCC, CE, RoHS |
| Input voltage | 5 V |
| Harmonized System (HS) code | 84716070 |
| Scanning | |
|---|---|
| Scanner type | 1D |
| Linear (1D) barcodes supported | Code 11, Code 128, Code 32, Code 39, Code 93, GS1-128 (UCC/EAN-128), JAN |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Working distance | 50 cm |
| Read rate (max) | 500 reads/s |
| Light levels (direct sunlight) | 0 - 10000 lx |
| Image sensor | |
|---|---|
| Sensor type | CCD |
| Optical fiber | |
|---|---|
| Wavelength | 632 nm |
| Paper handling | |
|---|---|
| Maximum scan width | 50 cm |
| Keyboard | |
|---|---|
| Connectivity technology | Wired |
| Other features | |
|---|---|
| Standard interfaces | Keyboard wedge, RS-232, USB |
| Design | |
|---|---|
| Product colour | Black |
| Housing material | Acrylonitrile butadiene styrene (ABS), Rubber |
| International Protection (IP) code | IP54 |
| LED indicators | Y |
| Power | |
|---|---|
| Power consumption | 70 mA |
| Weight & dimensions | |
|---|---|
| Weight | 150 g |
| Width | 70 mm |
| Depth | 180 mm |
| Height | 70 mm |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Product Description
Improve speed, accuracy and productivity._x000D_
_x000D_
_x000D_
Manhattan Linear CCD Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts, and has a rugged impact-resistant housing for years of reliable service of reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. With a scan rate of 500 scans per second and an accurate read range of up to 500 mm (20 in.), this model offers a high-performance, all-purpose daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
_x000D_
_x000D_
Manhattan Linear CCD Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts, and has a rugged impact-resistant housing for years of reliable service of reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. With a scan rate of 500 scans per second and an accurate read range of up to 500 mm (20 in.), this model offers a high-performance, all-purpose daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
