Samsung QE85T Digital signage flat panel 2.16 m (85") LED 300 cd/m² 4K Ultra HD Black Built-in processor Tizen 4.0 16/7
Samsung QE85T, Digital signage flat panel, 2.16 m (85"), LED, 3840 x 2160 pixels, 16/7
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Samsung |
| Product code | 169036853 |
| EAN | 08806094453317 |
| Manufacturer part number | LH85QETELGCXEN |
| Display | |
|---|---|
| Display diagonal | 2.16 m (85") |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 300 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 4000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.4875 x 0.4875 mm |
| Colour saturation | 72% |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
| Haze rate | 2% |
| Other features | |
|---|---|
| Active display area (W x H) | 1872 x 1053 mm |
| RS-232 interface | Y |
| Remote control included | Y |
| Quick start guide | Y |
| Ports & interfaces | |
|---|---|
| HDMI ports quantity | 2 |
| USB port | Y |
| HDMI version | 2.0 |
| USB ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Network | |
|---|---|
| Ethernet LAN | Y |
| Features | |
|---|---|
| USB version | 2.0 |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| VESA mounting | Y |
| Panel mounting interface | 600 x 400 mm |
| HDCP | Y |
| HDCP version | 2.2 |
| Built-in processor | Y |
| Certification | Safety 60950-1, |
| Inputs | |
|---|---|
| Audio (L/R) in | 1 |
| Outputs | |
|---|---|
| Audio (L/R) out | 1 |
| Audio | |
|---|---|
| Built-in speaker(s) | Y |
| Number of built-in speakers | 1 |
| Speaker impedance | 2 Ω |
| Multimedia | |
|---|---|
| RMS rated power | 10 W |
| Design | |
|---|---|
| Product colour | Black |
| Orientation | Horizontal |
| Mouse | |
|---|---|
| Purpose | Universal |
| Performance | |
|---|---|
| Operating hours (hours/days) | 16/7 |
| Power | |
|---|---|
| Power consumption (typical) | 208 W |
| Power consumption (max) | 273 W |
| Power consumption (sleep) | 0.5 W |
| AC input voltage | 100 - 200 V |
| AC input frequency | 50/60 Hz |
| Processor | |
|---|---|
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor model | Cortex-A72 |
| Processor frequency | 1.7 GHz |
| Memory | |
|---|---|
| Internal memory | 2 GB |
| Software | |
|---|---|
| Operating system installed | Tizen 4.0 |
| Media formats | |
|---|---|
| Video formats supported | AVS+, H.263, H.264, HEVC, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9 |
| Audio formats supported | AC3 |
| Image formats supported | JPEG, PNG |
| Weight & dimensions | |
|---|---|
| Width | 1900.9 mm |
| Depth | 1086.2 mm |
| Height | 26.9 mm |
| Weight | 41.5 kg |
| Package weight | 54.3 kg |
| Packaging data | |
|---|---|
| Package width | 2075 mm |
| Package depth | 220 mm |
| Package height | 1237 mm |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Heat dissipation (max) | 930.9 BTU/h |
Product Description
Upgrade your business with efficient digital displays
Samsung’s QET series features intelligent upscaling technology that displays all content in eye-catching UHD resolution along with a boundless design and simple content management features.
Incredible UHD picture quality
Samsung’s QET series is able to capture customer attention by providing an incredibly clear picture, showcasing lifelike images in advanced picture quality than ever before.
Crystal Display
Samsung’s QET series features a Crystal Display which optimizes color tones without distortion, ensuring each backlight unit is fine-tuned to match each color filter and create a clear native white.
Crystal Processor 4K
Intelligent UHD upscaling technology, made possibly by Samsung’s Crystal Processor 4K, allows content developed at a lower resolution to be elevated to UHD-level quality. It also performs edge restoration and noise reduction to optimize on-screen text and imagery.
Boundless design for an immersive experience
The boundless design of the display is optimized to allow the viewer to be completely immersed by content and the display seamlessly integrates into any business environment.
Integrated content management solution
With a range of on-demand images and videos, MagicINFO Lite Player makes content management easier than ever before. New content can be added from a personal computer or USB drive by connecting directly to the display.
