Sony SRG-A40 8.5 MP Black 3840 x 2160 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
Sony SRG-A40, 8.5 MP, CMOS, 4K Ultra HD, 3840 x 2160 pixels, 60 fps, 30x
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Sony |
| Product code | 2210477626 |
| EAN | 04548736143388 |
| Manufacturer part number | SRG-A40BC |
| Category | Video conferencing equipment |
| Performance | |
|---|---|
| Megapixel | 8.5 MP |
| Light exposure modes | Manual, Auto, Shutter priority AE |
| PTZ control | Yes |
| PTZ protocols | VISCA |
| Power source type | AC, DC |
| Auto framing | Yes |
| Audio channels | 2 |
| Picture quality | |
|---|---|
| Camera type | Single camera |
| Image sensor | |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Camera | |
|---|---|
| Zoom capability | Yes |
| Optical zoom | 30x |
| Horizontal field of view (wide) | 70° |
| Minimum illumination | 1.6 lx |
| White balance | Indoor, One push, Outdoor, Auto, Manual, Daylight |
| Auto exposure | Yes |
| Gain control type | Auto/Manual |
| Minimum working distance (wide) | 8 cm |
| Maximum working distance (tele) | 80 cm |
| Slowest camera shutter speed | 1 s |
| Fastest camera shutter speed | 1/10000 s |
| Maximum video resolution | 3840 x 2160 pixels |
| Image stabilizer | Yes |
| Pan range | -170 - 170° |
| Lens system | |
|---|---|
| Focal length range | 4.4 - 88 mm |
| Focus adjustment | Auto/Manual |
| Video | |
|---|---|
| Flip & mirror | Yes |
| Maximum frame rate | 60 fps |
| Number of TV lines | 1700 |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Features | |
|---|---|
| Aperture range (F-F) | 2 - 3.8 |
| Supported graphics resolutions | 3840 x 2160, 1920 x 1080 (HD 1080), 640 x 360, 1280 x 720 (HD 720) |
| Display | |
|---|---|
| HD type | 4K Ultra HD |
| Media formats | |
|---|---|
| Video formats supported | H.264, H.265 |
| Design | |
|---|---|
| Product colour | Black |
| Tally light | Yes |
| Tilt speed (min) | 0.5 °/sec |
| Tilt speed (max) | 126 °/sec |
| Pan speed (min) | 0.5 °/sec |
| Pan speed (max) | 300 °/sec |
| Ergonomics | |
|---|---|
| Tilt angle range | -20 - 90° |
| Ports & interfaces | |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| 3G-SDI output | Yes |
| Microphone in | Yes |
| VISCA output ports | 1 |
| VISCA input ports | 1 |
| Power | |
|---|---|
| DC input voltage | 19.5 V |
| Power consumption (typical) | 80 W |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Power supply | |
|---|---|
| Power supply included | Yes |
| Packaging content | |
|---|---|
| Cables included | AC, HDMI |
| Warranty card | Yes |
| Packaging data | |
|---|---|
| Screws included | Yes |
| Mounting brackets included | Yes |
| Software | |
|---|---|
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey |
| Audio | |
|---|---|
| Audio codecs | AAC LC 256kbps/ST (IP), AAC LC 128kbps/ST(IP) |
| Bit rate range | 512 - 50000 Kbit/s |
| Network | |
|---|---|
| Multi-stream capability | 3 |
| Protocols | |
|---|---|
| Supported network protocols | IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT |
| Weight & dimensions | |
|---|---|
| Width | 156.7 mm |
| Depth | 200 mm |
| Height | 184 mm |
| Weight | 2 kg |
Product Description
SRG-A40 with PTZ Auto Framing
Revolutionary PTZ Auto Framing technology powered by built-in AI analytics ensures high quality composed shots without operator.
Shooting redefined. AI makes you free.
A Camera that Automatically and Naturally Shoots Video for you
With the advanced PTZ Auto Framing feature, the camera automatically track the target in a comfortable viewing with smooth Pan-Tilt-Zoom movement regardless of posture, movement and what one is wearing.
Since the camera does most of the work automatically, the operator can spend its time efficiently.
PTZ Auto Framing with built-in AI analytics
This camera harnesses powerful AI-powered video analytics that can automatically detect and track the position of a presenter within the camera frame. As the presenter moves, the camera’s pan/tilt/zoom mechanism ensures that the presenter is always framed naturally, without the need for a human camera operator to manually follow their movements.
Automatically and reliably shoots video for you
With Sony’s newly developed AI analytics algorithm, it detects the subject’s skeleton and head position and matches the subject’s detail features even when there are several people in the frame. It achieves accurate framing and consistent tracking.
Choice from three shooting modes
The camera has a choice of three shooting modes; Full body, Waist, and Close up. In each mode, you can adjust picture composition (size, up & down, and left & right) and the SRG-A40 and SRG-A12 can automatically track and keep the subject in the selected optimal position.
Integrated tally lamp
The SRG-A40 and SRG-A12 feature a built-in tally lamp, just like you’d find on professional studio cameras. The lamp illuminates to give presenters visual confirmation of shooting status, or to show that PTZ Auto Framing mode is active. The lamp colour will change from Red (On Air) to Green (PTZ Auto Framing ON).
Remote control of PTZ operation
Pan/Tilt/Zoom camera movements and other functions can all be precisely controlled using the supplied IR remote controller, for convenient wireless control of PTZ functions without needing additional equipment. It can also be controlled using the optional additional RM-IP500 remote controller, just like professional broadcast cameras.
Easy ceiling mounting
The camera comes supplied with a mounting plate for convenient ceiling installation if required.
Light, compact design
The camera’s stylish, compact body fits unobtrusively into any environment.
Choice of colour finishes
The camera is available in a choice of black or while colour finishes, to suit the needs of any application.
Revolutionary PTZ Auto Framing technology powered by built-in AI analytics ensures high quality composed shots without operator.
Shooting redefined. AI makes you free.
A Camera that Automatically and Naturally Shoots Video for you
With the advanced PTZ Auto Framing feature, the camera automatically track the target in a comfortable viewing with smooth Pan-Tilt-Zoom movement regardless of posture, movement and what one is wearing.
Since the camera does most of the work automatically, the operator can spend its time efficiently.
PTZ Auto Framing with built-in AI analytics
This camera harnesses powerful AI-powered video analytics that can automatically detect and track the position of a presenter within the camera frame. As the presenter moves, the camera’s pan/tilt/zoom mechanism ensures that the presenter is always framed naturally, without the need for a human camera operator to manually follow their movements.
Automatically and reliably shoots video for you
With Sony’s newly developed AI analytics algorithm, it detects the subject’s skeleton and head position and matches the subject’s detail features even when there are several people in the frame. It achieves accurate framing and consistent tracking.
Choice from three shooting modes
The camera has a choice of three shooting modes; Full body, Waist, and Close up. In each mode, you can adjust picture composition (size, up & down, and left & right) and the SRG-A40 and SRG-A12 can automatically track and keep the subject in the selected optimal position.
Integrated tally lamp
The SRG-A40 and SRG-A12 feature a built-in tally lamp, just like you’d find on professional studio cameras. The lamp illuminates to give presenters visual confirmation of shooting status, or to show that PTZ Auto Framing mode is active. The lamp colour will change from Red (On Air) to Green (PTZ Auto Framing ON).
Remote control of PTZ operation
Pan/Tilt/Zoom camera movements and other functions can all be precisely controlled using the supplied IR remote controller, for convenient wireless control of PTZ functions without needing additional equipment. It can also be controlled using the optional additional RM-IP500 remote controller, just like professional broadcast cameras.
Easy ceiling mounting
The camera comes supplied with a mounting plate for convenient ceiling installation if required.
Light, compact design
The camera’s stylish, compact body fits unobtrusively into any environment.
Choice of colour finishes
The camera is available in a choice of black or while colour finishes, to suit the needs of any application.
