StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)
StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters), VGA, Serial, RS-232, Silver, DC, 0 - 70 °C
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | StarTech.com |
| Product code | 16732578 |
| EAN | 00065030842402 |
| Manufacturer part number | RS232EXTC1EU |
| Category | Serial cables and adapters |
| Ports & interfaces | |
|---|---|
| Host interface | VGA |
| Output interface | Serial |
| Serial interface type | RS-232 |
| Ethernet LAN (RJ-45) ports | 1 |
| Rear panel I/O ports | |
|---|---|
| Serial ports quantity | 1 |
| Performance | |
|---|---|
| Internal | N |
| Design | |
|---|---|
| Product colour | Silver |
| Features | |
|---|---|
| Power supply type | DC |
| Data transfer rate | 0.115 Mbit/s |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | 0 - 85 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
|---|---|
| Width | 65 mm |
| Depth | 92 mm |
| Height | 22 mm |
| Weight | 1 kg |
| Packaging data | |
|---|---|
| Package width | 57 mm |
| Package depth | 315 mm |
| Package height | 138 mm |
| Keyboard | |
|---|---|
| Connectivity technology | Wired |
| Other features | |
|---|---|
| Power requirements | 115V |
Product Description
Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling
The RS232EXTC1EU Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Serial Extender is a cost-effective serial extension solution and entirely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
- Pure hardware design, no software or drivers required ensuring a simple plug and play installation
- Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located
The RS232EXTC1EU Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Serial Extender is a cost-effective serial extension solution and entirely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
- Pure hardware design, no software or drivers required ensuring a simple plug and play installation
- Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located
