Techly Audio Extractor 2CH LPCM HDMI 4K UHD 3D IDATA HDMI-EA4K
Techly Audio Extractor 2CH LPCM HDMI 4K UHD 3D IDATA HDMI-EA4K, 5 V, 95 mm, 82 mm, 23 mm, 448 g
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Techly |
| Product code | 717853209 |
| EAN | 08054529025749 |
| Manufacturer part number | IDATA HDMI-EA4K |
| Category | Extension tube |
| Ports & interfaces | |
|---|---|
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Outputs | |
|---|---|
| Audio (L/R) out | 1 |
| Rear panel I/O ports | |
|---|---|
| Digital audio optical out | 1 |
| Performance | |
|---|---|
| Maximum transfer distance | 10 m |
| Features | |
|---|---|
| HDCP | Y |
| HDCP version | 1.2 |
| Harmonized System (HS) code | 85176990 |
| Certification | CE, RoHS |
| Design | |
|---|---|
| Product colour | Black |
| On/off switch | Y |
| Sustainability | |
|---|---|
| Sustainability certificates | CE, RoHS |
| Power | |
|---|---|
| Operating voltage | 5 V |
| Weight & dimensions | |
|---|---|
| Width | 95 mm |
| Depth | 82 mm |
| Height | 23 mm |
| Weight | 448 g |
Product Description
IDATA HDMI-EA4K extracts the audio signal from the HDMI source and convert it to optical or analog multi-channel digital audio.
It allows you to easily send the HDMI video signal to a TV, projector or monitor and send the HDMI audio signals to external speakers.
Features
- It extracts the audio signal from an HDMI source
- Supports HDMI audio sampling rates up to 192kHz
- Supports optical audio sampling rate S / PDIF audio up to 192kHz
- Supports audio sampling frequency L / R up to 48 kHz
- Supports audio HDMI high-bit-rate (HBR)
- No HDMI connections for receiving audio on analog and optical outputs
- Supports analog stereo audio output L / R and S / PDIF optical
- Incoming and outgoing can use HDMI cables up to 15 meters in length 1080p 8bit resolution, or 10m to 1080p 12bit
- Supports audio feature EDID between LPCM 2CH, TV EDID (external) and Audio Bitstream
- Allows 4Kx2K resolutions and 3D reproductions
- Meets HDMI, HDCP 1.2 and DVI 1.0
- Black Colour
Technical Specifications
- Video bandwidth: 300Mbps / 10.2Gbps
- Input ports: 1 x HDMI
- Output Ports: 1 x HDMI, 1 x Optical, 1 x L / R (3.5 "female)
- HDMI Audio sampling frequency up to 192kHz
- SPDIF Optical Audio sampling frequency up to 192 kHz
- HDMI Audio format: 2CH LPCM, Dolby Digital 2 ~ 5.1CH, DTS 5.1 CH 2 ~
- Audio Format L / R: Stereo Analog 2CH
- Cable distance HDMI 4K I / O: 10m / 10m
- Power supply included 5V 2A
Environmental Features
- Operating Temperature: 0 ° C ~ 40 ° C
- Storage Temperature: -20˚C ~ 60˚C
Dimensions
- Width: 95 mm
- Depth: 82 mm
- Height: 23 mm
Certifications
- EC
- FCC
- WEEE
