Techly IDATA EXT-E70POED AV extender AV transmitter & receiver Black
Techly IDATA EXT-E70POED, 1920 x 1080 pixels, AV transmitter & receiver, 40 m, Wired, 3D, HDCP
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Techly |
| Product code | 363966775 |
| EAN | 08051128100709 |
| Manufacturer part number | IDATA-EXT-E70POED |
| Category | Other AV & electronics |
| Features | |
|---|---|
| Type | AV transmitter & receiver |
| Supported video modes | 480i,480p,576i,576p,720p,1080i,1080p |
| HDCP | Y |
| HDCP & EDID bypass | Y |
| Certification | EC FCC WEEE |
| Graphics | |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Network | |
|---|---|
| Cable types supported | Cat6,Cat6a,Cat7 |
| Performance | |
|---|---|
| Maximum transfer distance | 40 m |
| Media formats | |
|---|---|
| Audio formats supported | AC3,PCM |
| Other features | |
|---|---|
| 3D | Y |
| Design | |
|---|---|
| Product colour | Black |
| Keyboard | |
|---|---|
| Connectivity technology | Wired |
| Power | |
|---|---|
| Power consumption (transmitter) (max) | 3 W |
| Power consumption (receiver) (max) | 3 W |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Y |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Weight & dimensions | |
|---|---|
| Width | 71.6 mm |
| Depth | 66.9 mm |
| Height | 22.6 mm |
| Packaging content | |
|---|---|
| Manual | Y |
| Sustainability | |
|---|---|
| Sustainability certificates | RoHS |
Product Description
This HDMI Extender allows you to transmit HDTV signal over long distances using a Cat. 6 / 6A / 7 network cable.
Thanks to the use of Network Cable you can reach up to 40m of transmission length with a video resolution of 1080p.
Thanks to the Extended Display Identification Data (EDID) function via the switch, you can adjust the signal to the correct resolution and frequency and get the optimum and maximum quality from the HDMI signal.
IDATA EXT-E70POED can be used canonically through the supplied power supplies or you can leverage the POE function to power the receiver.
The product also features infrared IR synchronization technology, supports 3D signal and is HDCP 1.2a.
Thanks to its versatility it can be used in any environment of both work and leisure as public places, studios, offices and conference rooms or just for home use.
Thanks to the use of Network Cable you can reach up to 40m of transmission length with a video resolution of 1080p.
Thanks to the Extended Display Identification Data (EDID) function via the switch, you can adjust the signal to the correct resolution and frequency and get the optimum and maximum quality from the HDMI signal.
IDATA EXT-E70POED can be used canonically through the supplied power supplies or you can leverage the POE function to power the receiver.
The product also features infrared IR synchronization technology, supports 3D signal and is HDCP 1.2a.
Thanks to its versatility it can be used in any environment of both work and leisure as public places, studios, offices and conference rooms or just for home use.
