Toote tegelik värvus võib erineda piltidel kujutatavast ning pildid on
illustratiivsed.
TP-Link EAP110 wireless access point 300 Mbit/s White Power over Ethernet (PoE)
TP-Link EAP110, 300 Mbit/s, 300 Mbit/s, 10,100 Mbit/s, 2.4 - 2.4835 GHz, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, 10/100Base-T(X)
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | TP-Link |
| Product code | 414587696 |
| Manufacturer part number | EAP110 |
| Features | |
|---|---|
| 2.4 GHz | Y |
| 5 GHz | N |
| Maximum data transfer rate | 300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Wi-Fi Multimedia (WMM)/(WME) | Y |
| Wireless isolation | Y |
| Placement | Ceiling, Wall |
| Certification | FCC, RoHS |
| Antenna type | Internal |
| Antenna gain level (max) | 4 dBi |
| Harmonized System (HS) code | 85176990 |
| Network | |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Cabling technology | 10/100Base-T(X) |
| Automatic channel selection | Y |
| VLAN support | Y |
| Virtual LAN features | SSID-based VLAN assignment |
| Rate limiting | Y |
| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
| Mouse | |
|---|---|
| Frequency band | 2.4 - 2.4835 GHz |
| Other features | |
|---|---|
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x |
| Antennas quantity | 2 |
| Quick start guide | Y |
| Management features | |
|---|---|
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Design | |
|---|---|
| Transmitting power (CE) | 21 dBm |
| Receiver sensitivity | 300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER |
| Product colour | White |
| Reset button | Y |
| LED indicators | Power |
| Security | |
|---|---|
| MAC address filtering | Y |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Number of SSID supported | 8 |
| Remote Authentication Dial-In User Service (RADIUS) | Y |
| Access Control List (ACL) | Y |
| Performance | |
|---|---|
| Syslog | Y |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Y |
| Power | |
|---|---|
| AC input voltage | 24 V |
| Power consumption (typical) | 2.8 W |
| Antenna | |
|---|---|
| Antenna direction type | Omni-directional |
| Weight & dimensions | |
|---|---|
| Width | 189.4 mm |
| Depth | 172.3 mm |
| Height | 29.5 mm |
| Packaging data | |
|---|---|
| Package type | Box |
| Number of products included | 1 pc(s) |
| PoE adapter included | Y |
| Packaging content | |
|---|---|
| Cables included | AC |
| Mounting kit | Y |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Product Description
Flexible Placement
Easy mounting design & PoE
The EAP’s elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.
Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Efficient Guest Authentication with Facebook and SMS Support
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.
Easy mounting design & PoE
The EAP’s elegant appearance and easy mounting design with chassis make it easy to be integrated seamlessly into any wall or ceiling surface to blend in with most interior decorations. EAP110 supports Passive PoE to make deployment effortless and flexible.
Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Efficient Guest Authentication with Facebook and SMS Support
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.
