Viewsonic LS610HDH data projector Short throw projector 4000 ANSI lumens DMD 1080p (1920x1080) White
Viewsonic LS610HDH, 4000 ANSI lumens, DMD, 1080p (1920x1080), 3000000:1, 762 - 7620 mm (30 - 300"), 0.87 - 10.38 m
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Viewsonic |
| Product code | 167764131 |
| EAN | 05704174956952 |
| Manufacturer part number | LS610HDH |
| Category | Projectors |
| Projector | |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DMD |
| Projector native resolution | 1080p (1920x1080) |
| Projection distance | 0.87 - 10.38 m |
| Number of colours | 1.07 billion colours |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
| Display | |
|---|---|
| Contrast ratio (typical) | 3000000:1 |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 23 - 120 Hz |
| On Screen Display (OSD) | Y |
| Design | |
|---|---|
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Product type | Short throw projector |
| Market positioning | Presentation |
| Product colour | White |
| Built-in display | N |
| Light source | |
|---|---|
| Light source type | LED |
| Service life of light source | 30000 h |
| Lens system | |
|---|---|
| Fixed focal length | 1.92 cm |
| Offset | 83% |
| Features | |
|---|---|
| Aperture range (F-F) | 1.6 - 1.75 |
| Throw ratio | 1.3-1.56 |
| Supported graphics resolutions | 640 x 480 (VGA), 3840 x 2160 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Interactive | N |
| Noise level (economic mode) | 27 dB |
| HDCP | Y |
| Placement | Ceiling, Desktop |
| Camera | |
|---|---|
| Zoom capability | Y |
| Performance | |
|---|---|
| Full HD | Y |
| Ports & interfaces | |
|---|---|
| HDMI ports quantity | 2 |
| DVI port | N |
| Serial interface type | RS-232 |
| HDMI connector type | Full-size |
| HDMI version | 1.4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Other features | |
|---|---|
| USB 2.0 ports quantity | 1 |
| Noise level | 32 dB |
| Remote control included | Y |
| Network | |
|---|---|
| Smart TV | N |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Storage | |
|---|---|
| Card reader integrated | N |
| Ergonomics | |
|---|---|
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Number of OSD languages | 20 |
| Audio | |
|---|---|
| Built-in speaker(s) | Y |
| Number of built-in speakers | 1 |
| Multimedia | |
|---|---|
| RMS rated power | 10 W |
| Power | |
|---|---|
| Power source | AC |
| Power consumption (typical) | 330 W |
| Power consumption (standby) | 0.5 W |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 100 - 240 V |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 5 kg |
| Width | 386 mm |
| Depth | 276 mm |
| Height | 116 mm |
| Package weight | 7 kg |
| Packaging data | |
|---|---|
| Package width | 490 mm |
| Package depth | 376 mm |
| Package height | 268 mm |
| Packaging content | |
|---|---|
| Manual | Y |
Product Description
3rd Generation LED Technology for Greater Sustainability
With the 3rd generation LED technology, the LS610HDH frees users from frequent lamp replacement and toxic mercury. Offering consistently impressive brightness for 30,000 hours, the projector saves the cost of time, manpower and money for maintenance, while providing a greener and more sustainable future.
Saving More with the Advanced LED Technology
Adopting ams OSRAM’s Ostar Projection Power LED technology, the LED projector is both energy saving and cost efficient, consuming less energy than competing lamp-based projectors.
Enhanced Brightness for Business/Education Environments
Thanks to the latest LED technology, the LS610HDH achieves a major brightness breakthrough to 4,000 ANSI Lumens.With extreme-high contrast ratio of 3,000,000:1, the projector ensures bright and detailed images in dim or lit environments.
Present the Best with Vibrant Colors
Impress any audience with ViewSonic’s exclusive color technology, covering wide color gamut, elevating your presentation with a true-to-life color experience.
Clearly Showcase Your Ideas with 1080p Full HD
The LS610HDH delivers crisp high-quality visuals in 1080p resolution with HDR and HLG support, for smooth presentations and engaging collaborations.
Effortless Image Adjustment
Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.
Efficient Instant Power On/Off
Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.
Versatile Application
The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or floors.
Centralized Control for Management Efficiency
The LS610HDH is compatible with Crestron, AMX, PJ Link, ATEN and Extron systems and comes equipped with ViewSonic vController, an easy-to-use network management tool.
USB Type A Power Supply
The built-in 5V/1.5A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming multimedia content.
Non-stop 24/7 Operation
The advanced cooling design enables 24/7 operation without degradation of image quality or work performance, making the projector ideal for applications that require continuous use.
Sealed Optical Engine with IP5X
Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.
With the 3rd generation LED technology, the LS610HDH frees users from frequent lamp replacement and toxic mercury. Offering consistently impressive brightness for 30,000 hours, the projector saves the cost of time, manpower and money for maintenance, while providing a greener and more sustainable future.
Saving More with the Advanced LED Technology
Adopting ams OSRAM’s Ostar Projection Power LED technology, the LED projector is both energy saving and cost efficient, consuming less energy than competing lamp-based projectors.
Enhanced Brightness for Business/Education Environments
Thanks to the latest LED technology, the LS610HDH achieves a major brightness breakthrough to 4,000 ANSI Lumens.With extreme-high contrast ratio of 3,000,000:1, the projector ensures bright and detailed images in dim or lit environments.
Present the Best with Vibrant Colors
Impress any audience with ViewSonic’s exclusive color technology, covering wide color gamut, elevating your presentation with a true-to-life color experience.
Clearly Showcase Your Ideas with 1080p Full HD
The LS610HDH delivers crisp high-quality visuals in 1080p resolution with HDR and HLG support, for smooth presentations and engaging collaborations.
Effortless Image Adjustment
Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.
Efficient Instant Power On/Off
Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.
Versatile Application
The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or floors.
Centralized Control for Management Efficiency
The LS610HDH is compatible with Crestron, AMX, PJ Link, ATEN and Extron systems and comes equipped with ViewSonic vController, an easy-to-use network management tool.
USB Type A Power Supply
The built-in 5V/1.5A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming multimedia content.
Non-stop 24/7 Operation
The advanced cooling design enables 24/7 operation without degradation of image quality or work performance, making the projector ideal for applications that require continuous use.
Sealed Optical Engine with IP5X
Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.
