Viewsonic PA503W data projector Standard throw projector 3800 ANSI lumens DMD WXGA (1280x800) White
Viewsonic PA503W, 3800 ANSI lumens, DMD, WXGA (1280x800), 22000:1, 762 - 7620 mm (30 - 300"), 1 - 10.98 m
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Viewsonic |
| Product code | 07294825 |
| EAN | 07669079049186 |
| Manufacturer part number | VS16907 |
| Category | Projectors |
| Projector | |
|---|---|
| Projector brightness | 3800 ANSI lumens |
| Projection technology | DMD |
| Projector native resolution | WXGA (1280x800) |
| Projection distance | 1 - 10.98 m |
| Number of colours | 1.07 billion colours |
| Keystone correction, vertical | -40 - 40° |
| Matrix size | 1.65 cm (0.65") |
| Display | |
|---|---|
| Contrast ratio (typical) | 22000:1 |
| Horizontal scan range | 15 - 102 kHz |
| Vertical scan range | 23 - 120 Hz |
| On Screen Display (OSD) | Y |
| Design | |
|---|---|
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Product type | Standard throw projector |
| Market positioning | Presentation |
| Product colour | White |
| Built-in display | N |
| Light source | |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 15000 h |
| Lamp power | 200 W |
| Packaging content | |
|---|---|
| Lamps quantity | 1 lamp(s) |
| Cables included | AC, VGA |
| Manual | Y |
| Lens system | |
|---|---|
| Focus | Manual |
| Focal length range | 22 - 24.1 mm |
| Zoom ratio | 2.0:1 |
| Offset | 100% |
| Features | |
|---|---|
| Aperture range (F-F) | 2.56 - 2.68 |
| Throw ratio | 1.55-1.7 |
| Supported graphics resolutions | 640 x 480 (VGA),1920 x 1080 (HD 1080) |
| Supported video modes | 480i,480p,576i,576p,720p,1080i,1080p |
| Interactive | N |
| Noise level (economic mode) | 27 dB |
| HDCP | Y |
| Placement | Desktop, Ceiling |
| Camera | |
|---|---|
| Zoom capability | Y |
| Video | |
|---|---|
| Analog signal format system | NTSC,PAL,SECAM |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 1 |
| Composite video in | 1 |
| DVI port | N |
| Serial interface type | RS-232 |
| HDMI connector type | Full-size |
| HDMI version | 1.4 |
| Mini-USB 2.0 ports quantity | 1 |
| PC Audio in | Y |
| PC Audio out | Y |
| Mobile High-Definition Link (MHL) | N |
| AC (power) in | Y |
| Network | |
|---|---|
| Smart TV | N |
| Ethernet LAN | N |
| Wi-Fi | N |
| Storage | |
|---|---|
| Card reader integrated | N |
| Other features | |
|---|---|
| Noise level | 31 dB |
| Remote control included | Y |
| Ergonomics | |
|---|---|
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Number of OSD languages | 22 |
| Audio | |
|---|---|
| Built-in speaker(s) | Y |
| Multimedia | |
|---|---|
| RMS rated power | 2 W |
| Power | |
|---|---|
| Power source | AC |
| Power consumption (typical) | 260 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 2.2 kg |
| Width | 294 mm |
| Depth | 218 mm |
| Height | 110 mm |
| Package weight | 3.24 kg |
| Packaging data | |
|---|---|
| Package width | 365 mm |
| Package depth | 300 mm |
| Package height | 188 mm |
Product Description
Description
The ViewSonic PA503W price-performance projector features 3,600 lumens, native WXGA 1280x800 resolution, and an intuitive, user-friendly design. Exclusive SuperColor technology offers a wider color range for lifelike image projection. The PA503w also features extensive connectivity including HDMI, 2 x VGA in, Composite Video, 1 x VGA output, and Audio in/out. An energy-saving SuperEco feature reduces power consumption by up to 70%, and extends the lamp life by up to 10,000 hours. With advanced audiovisual features, flexible connectivity options, and an affordable price, the PA503W is ideal for use in education and small business environments.
