Zyxel XGS1930-28 Managed L3 Gigabit Ethernet (10/100/1000) Black
Zyxel XGS1930-28, Managed, L3, Gigabit Ethernet (10/100/1000), Rack mounting
Read more...
Read more...
Product Information
| Information | |
|---|---|
| Manufacturer | Zyxel |
| Product code | 14368680 |
| EAN | 00760559124694 |
| Manufacturer part number | NUZYXSZ24P00016 |
| Category | Switches & accessories |
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Optical fiber | |
|---|---|
| Fiber optic connector | SFP+ |
| Other features | |
|---|---|
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Number of VLANs | 4000 |
| Internal memory | 512 MB |
| Network | |
|---|---|
| 10G support | Y |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Port mirroring | Y |
| IP routing | Y |
| Routing entries | 32 |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Virtual LAN features | Voice VLAN,Port-based VLAN |
| Path MTU discovery | Y |
| Security algorithms | 802.1x RADIUS,HTTPS,SHA-2,SNMPv3,SSL/TLS |
| Features | |
|---|---|
| Flow control support | Y |
| Certification | RoHS |
| Data transmission | |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Forwarding rate | 95.2 Mpps |
| Static route | Y |
| Packet buffer memory | 1.5 MB |
| Security | |
|---|---|
| DHCP features | DHCP relay,DHCPv6 relay,DHCP client |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| SSH/SSL support | Y |
| Loop protection | Y |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Password protection | Y |
| CPU defense | Y |
| Multicast features | |
|---|---|
| Multicast support | Y |
| Protocols | |
|---|---|
| GARP VLAN Registration Protocol (GVRP) | Y |
| Design | |
|---|---|
| Rack mounting | Y |
| Product colour | Black |
| Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
| Performance | |
|---|---|
| Safety | LVD, BSMI |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 1211024 h |
| Heat dissipation | 83.886 BTU/h |
| Power | |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 24.6 W |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | N |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 441 mm |
| Depth | 270 mm |
| Height | 44 mm |
| Weight | 3.4 kg |
| Package weight | 4.47 kg |
| Packaging content | |
|---|---|
| Cables included | AC |
| Rack mount kit | Y |
| Packaging data | |
|---|---|
| Package width | 616 mm |
| Package depth | 355 mm |
| Package height | 107 mm |
Product Description
The most affordable choice for 10G migration
The XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.
Built for convenience
This smart-looking switch features an intuitive design that simplifies daily network management for SMBs.
Manage it your way!
The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.
Don’t overspend to upgrade your wired network
With Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
Whisper-quiet operation
Smart fan and fanless designs for silent operation in your workplace.
User-friendly LED indicators
View real-time status instantly with cloud and PoE power-usage LED indicators.
Power more devices more easily
- Provides 30W per port and a high power budget of 375W, ideal for denser PoE deployments.
- Default consumption mode boosts efficiency by delivering the actual power required.
Zyxel ONE Network
Use the complimentary ZON Utility to configure and discover switches, WLANs, and gateways in your network with one click.
Designed for the long haul
A web smart managed switch with an enterprise-grade hardware design. Built-in state-of-the-art hardware technology brings high quality and robustness to SMB networks.
The XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.
Built for convenience
This smart-looking switch features an intuitive design that simplifies daily network management for SMBs.
Manage it your way!
The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.
Don’t overspend to upgrade your wired network
With Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
Whisper-quiet operation
Smart fan and fanless designs for silent operation in your workplace.
User-friendly LED indicators
View real-time status instantly with cloud and PoE power-usage LED indicators.
Power more devices more easily
- Provides 30W per port and a high power budget of 375W, ideal for denser PoE deployments.
- Default consumption mode boosts efficiency by delivering the actual power required.
Zyxel ONE Network
Use the complimentary ZON Utility to configure and discover switches, WLANs, and gateways in your network with one click.
Designed for the long haul
A web smart managed switch with an enterprise-grade hardware design. Built-in state-of-the-art hardware technology brings high quality and robustness to SMB networks.
