Polaroid Solar Charge Controller 12/24V
Toote andmed
Toote kirjeldus
Polaroid Solar Charge Controller 12/24V
The Polaroid Solar Charge Controller is a PWM charge controller that uses advanced digital technology. It offers easy operation and cost-effective control with the following Features:
- 3-stage intelligent PWM charge: Bulk, Boost/Equalize, Float
- Supports 3 charging options: Sealed, Gel and Flooded (sealed)
- Battery status LED indicator can indicate battery status
- Battery temperature compensation function
- The personalized settings make operation more comfortable and simple
- USB provides a power supply that can charge electronic devices
- Battery type and load output adjustable via button
- Extensive electronic protection
Technical data:
- Nominal system voltage 12/24V automatic
- Rated charging current 10A
- Rated leakage current 10A
- Input voltage range 8~32V
- Max. PV open circuit voltage 50V
- IP20 protection
- Overall dimensions: 120.3 x 67 x 21.8mm
- Net weight 100 gr
- Operating temperature -35 °C to 55 °C
-
Technical Data
- Input:
- 5 V / 1,2 A
- Output Voltage (V):
- 10,6 - 16
- Max. Output Current (A):
- 10
- Charging Indicator:
- Yes
-
Energy Supply
- Laden über USB:
- Yes
- Charging via solar cells:
- Yes
-
Ports
- Input:
- USB-A 2.0
- Output:
- USB-A 2.0
-
General
- Colour:
- White
- Dimensions (mm):
- 120,3 x 67 x 21,8
- Weight (g):
- 111,5
