Tootepildid on illustratiivsed
Yala hotelli juurdepääsukontroll PNI CH2000R Gold paremal küljel oleva avamiskaardilugejaga
Toote andmed
| Üldandmed | |
|---|---|
| Tootja | PNI |
| Tootekood | 292317239 |
| EAN | 05949066507281 |
| Tootja kood | PNI-CH2000RG |
Toote kirjeldus
| Hotel access controlYala PNI CH2000R offers a standalone solution for security needs and access monitoring that a hotel has, be it large, medium or small. The body of the shaft is of a galvanized alloy offering resistance to impact or strokes. The door you want to mount must have a grommet between 30 and 50 mm. |
Electromagnetic card readerPNI CH2000R offers the possibility of opening a door with the help of an electromagnetic card. It is also provided with a backup key, which can be used in emergencies. Inside the yala has a manual opening mechanism. The CH2000R is compatible with 13.56 MHz PNI EMC-05 proximity cards . |
|
| |
| Open rightThe Yala PNI CH2000R can be used to open a door to the right looking from the outside of the room, as in the image attached. |
feedingYala PNI CH2000R is powered by 4 AA batteries. One set of batteries supports up to 10,000 openings. Yala warns when the voltage drops below 4.8V, a sign that the batteries need to be changed. |
|
| Monitoring softwareThe Yala PNI CH2000R can only be used in conjunction with the PNI FLH60 card programmer which also contains the monitoring software. Thus, you can configure a complex access control system. |
| Product identification | |
| Manufacturer | PNI |
| Product code | PNI-CH2000RG |
| Color | Golden |
| General characteristics | |
| feeding | 6V (4 x AA alkaline batteries) |
| Maximum consumption | 200 mA |
| Material | Others zincated |
| Anti-vandal | Yes |
| Card reader | EM card 13.56MHz |
| Mounting type | Apparent |
| Size / weight | 244 x 77 x 26mm / 3.4 kg |
| Operating temperature | -20 ~ 50 ° C |
| Working humidity | ≤ 80% |
| Yala opening type | Left Inside / Right Outside |
| Drive time | less than 1 second |
| Thick use | 30 - 50mm |
| Card drive distance | 0 - 5 cm from the sensor |
| The package contains | |
| Access control unit | Yes |
| Installation and use manual | Yes |
| Installation accessories | Yes |
